WIN AMMUNITION 147GR JHP RANGER T (50)

Description

Winchester Ranger 147gr JHP ammunition is designed for personal defense, offering reliable performance with controlled expansion and deep penetration. The T-Series features engineered segments in the patented SXT® design, enhancing stopping power.

• Shellcase: 9mm Luger nickel plated brass shellcase with cap lacquer
• Bullet: 147 grain (9.5 gram) SXT reverse tapered jacket, not blackened
• Diameter .355 inch (9.02 mm)
• Powder: Clean burning, low flash
• Primer: Winchester non-corrosive primer – boxer type
• Accuracy: Product Mean of 1.50 inch (3.81 cm) Extreme Spread
• 5 shot targets at 50 yards (45.7 m) from a 4 inch (10.2 cm) SAAMI test barrel
• Velocity: 985 ft/sec (300 m/s) nominal at 15 ft (4.6 m)
• Fired in a 4 inch (10.2 cm) standard SAAMI test barrel
• Energy: 317 ft-lb (430 joules)
• Pressure: 35,000 psi max. average (2,414 bars)
• Waterproofing: Lacquer applied to primer annulus
• Bullet Ballistic Coefficient: 0.197
Ballistics:
• Muzzle Velocity (FPS): 990
• Muzzle Energy (Ft. Lbs.): 320
• Test Barrel Length: 4.00 inches

Dimensions of box : 130mm w
66mm L
35mm H
